Ford 3230
| | 1990 - 1994 |
| 30 Utility Series | | Utility tractor |
|
Series map:
3230
3430
37.0hp
46.0hp
| Production |
| Manufacturer | Ford
|
| Utility tractor |
| Original price was $17,300 in 1994 |
| Ford 3230 Power |
| Engine | 37 hp
27.6 kW
|
| PTO (claimed) | 32 hp
23.9 kW
|
| Drawbar (tested) | 26.03 hp
19.4 kW
|
| PTO (tested) | 32.33 hp
24.1 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Steering | hydrostatic power
|
| Two-post ROPS. |
| Photos |
| No photos of the Ford 3230 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| | closed center (optional)
|
| Pressure | 2500 psi
172.4 bar
|
| Valves | 0 to 2 (open center)
|
| | 1 to 4 (closed center)
|
| Pump flow | 7.7 gpm
29.1 lpm
|
| | 12.8 gpm (optional)
48.4 lpm
|
| Steering flow | 3.6 gpm
13.6 lpm
|
| Tractor hitch |
| Rear Type | 2/1
|
| Control | position control with top link draft sensing
|
| Rear lift | 3,080 lbs
1397 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 55
|
| Battery CCA | 800
|
| Battery volts | 12
|
| References |
 |
| Front-End Loader 7310 published in 1994, by Ford |
| Front-end Loaders published in 1992, by Ford |
| Front-end Loaders published in 1995, by New Holland |
| 32 to 55 PTO hp Utility Tractors published in 1990, by Ford |
