Ford 2810


Ford 2810 tractor photo
1983 - 1990
10 Utility Series
Utility tractor
Series map:
2810
2910
34.3hp
40.5hp
Production
ManufacturerFord
Utility tractor
Original price was $16,000 in 1990
Ford 2810 Engine
Ford 2.6L 3-cyl diesel
Engine details ...
Ford 2810 Transmissions
8-speed
6-speed mechanical shuttle
Transmission details ...
Ford 2810 Power
Engine (gross)36.5 hp
27.2 kW
Engine34.3 hp
25.6 kW
PTO (claimed)32 hp
23.9 kW
Drawbar (tested)28.19 hp
21.0 kW
PTO (tested)32.83 hp
24.5 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Final drivesinboard planetary
Differential lockmechanical rear
Steeringmanual
 power assist OptOptional
Differential wet disc brakes
Two-post fixed ROPS.
Capacity
2WD Fuel13 gal
49.2 L
4WD Fuel16 gal
60.6 L
Hydraulic system12.1 gal
45.8 L
Steering3.6 qts
3.4 L
Hydraulics
Typeopen center
Capacity12.1 gal
45.8 L
Pressure2500 psi
172.4 bar
Pump flow7.7 gpm
29.1 lpm
Steering cap.3.6 qts
3.4 L
Tractor hitch
Rear TypeI
Controlposition and draft control
Rear lift2936 lbs
1331 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540
Engine RPM540@1800
Dimensions & Tires
2WD Wheelbase77.5 inches
196 cm
4WD Wheelbase84.1 inches
213 cm
Weight4420 to 4995 pounds
Front tire6.00-16
2WD Rear tire13.6-28
Full dimensions and tires ...
2810 Serial Numbers
Location:Identification plate inside the engine compartment
1983C694500
1984C707400
1985C732600
1986C750422
1987C763228
1986BA74292
1987BB05681
1988BB31777
1989BB80620
1990BC26239

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Mk I Charging amps32
Mk II Charging amps51
Battery volts12
Battery AH51
References
2810 references literature
Farm Loaders published in 1988, by Ford
Front-end Loaders published in 1989, by Ford
Front-end Loaders published in 1992, by Ford
Front-end Loaders published in 1995, by New Holland
32-52 hp Tractors published in 1985, by Ford
32-52 hp Tractors published in 1986, by Ford
32-52 hp Tractors published in 1987, by Ford
Tractor Buyer's Guide published in 1989, by Ford
Sales Reference Guide published in 1986, by Ford
