Ford 1910 Tests
|
|
| Tractor Tests | |
| NTTL 1507: diesel 12/4 gear 2WD | |
| NTTL 1508: diesel 12/4 synchro 2WD |
| Nebraska Tractor Test 1507 | |||
| |||
| Nebraska Tractor Test 1507 | |
| Diesel 12/4 gear 2WD March 30 - April 12, 1984 Link: Nebraska Tractor Test 1507 file | |
| PTO performance | |
| Power at rated engine speed | 28.60 hp 21.3 kW |
| Fuel use | 2.2 gal/hour 8.3 l/hour |
| Power at rated PTO speed | 28.29 hp 21.1 kW |
| Fuel use | 2.2 gal/hour 8.3 l/hour |
| Drawbar performance | |
| Max power | 24.76 hp 18.5 kW |
| Fuel use | 2.2 gal/hour 8.3 l/hour |
| Gear 3-3 used for power test. | |
| Max pull | 3,340 lbs 1515 kg |
| Gear 2-3 used for pull test. | |
| Nebraska Tractor Test 1508 | |||
| |||
| Nebraska Tractor Test 1508 | |
| Diesel 12/4 synchro 2WD March 30 - April 17, 1984 Link: Nebraska Tractor Test 1508 file | |
| PTO performance | |
| Power at rated engine speed | 28.52 hp 21.3 kW |
| Fuel use | 2.3 gal/hour 8.7 l/hour |
| Power at rated PTO speed | 28.30 hp 21.1 kW |
| Fuel use | 2.3 gal/hour 8.7 l/hour |
| Drawbar performance | |
| Max power | 24.57 hp 18.3 kW |
| Fuel use | 2.2 gal/hour 8.3 l/hour |
| Gear 3-3 used for power test. | |
| Max pull | 2,566 lbs 1163 kg |
| Gear 2-3 used for pull test. | |
