John Deere 5075E

John Deere 5075E tractor photo
2008 - 2017   5E Series
Model years
Utility tractor
Series next:John Deere 5083E
Series back:John Deere 5065E






Production:

Manufacturer:John Deere
Factory:Pune, Maharashtra, India


John Deere 5075E Engine:

   John Deere 2.9L 3-cyl diesel
full engine details ...


Capacity:

Fuel:18 gal [68.1 L]
2WD Hydraulic system:10 gal [37.9 L]
4WD Hydraulic system:10.3 gal [39.0 L]
Front axle:4.8 qts [4.5 L]
Front hubs:0.85 qts [0.8 L] *Each hub


Drawbar:

Drawbar:adjustable drawbar


3-Point Hitch:

Rear Type:2
Control:position and top-link draft control
Rear lift (at 24"/610mm):3,192 lbs [1447 kg]


Power Take-off (PTO):

Rear PTO:independent
Clutch:mechanical
Rear RPM:540
Engine RPM:540@2400


Dimensions & Tires:

Wheelbase:80.7 inches [204 cm]
Weight:4634 to 5475 pounds
Front tire:7.50-16
Rear tire:16.9-28 (2WD)
full dimensions and tires ...


John Deere 5075E attachments:

 front-end loader
all 5075E attachments ...


5075E Serial Numbers:


- Serial numbers unknown -



John Deere 5075E Power:

Engine (gross):75 hp [55.9 kW]
PTO (claimed):61 hp [45.5 kW]
PTO (tested):64.42 hp [48.0 kW]
power test details ...


Mechanical:

Chassis:4x2 2WD
 4x4 MFWD 4WD
Final drives:planetary
Differential lock:rear diff lock standard
Steering:hydrostatic power
Brakes:hydraulic wet disc
Cab:Folding 2-post ROPS. Optional canopy. Optional deluxe canopy with lights and insulation.


Hydraulics:

Type:open center
2WD Capacity:10 gal [37.9 L]
4WD Capacity:10.3 gal [39.0 L]
Pressure:2828 psi [195.0 bar]
Rear valves:1 or 2
Mid valves:2 (optional)
Pump flow:11.4 gpm [43.1 lpm]
Total flow:18.2 gpm [68.9 lpm]
Steering flow:6.8 gpm [25.7 lpm]
Steering press.:1958 psi [135.0 bar]


Electrical:

Ground:negative
Charging system:altenrator
Charging amps:40


Battery:

Number:1
Cold-cranking amps:623
Volts:12
