Tractors > Holder > A55 Cultitrac

Holder A55 Cultitrac



Holder A55 Cultitrac tractor photo
1973 - 1978
Production
ManufacturerHolder
Holder A55 Engine
Holder 2.0L 3-cyl diesel
Engine details ...
Holder A55 Transmission
8-speed
Transmission details ...
Holder A55 Power
Engine40 hp
29.8 kW
Mechanical
Four-wheel drive
Open operator station.
Photos
No photos of the Holder A55 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Hydraulic system2 gal
7.6 L
Hydraulics
Capacity2 gal
7.6 L
Pressure3000 psi
206.8 bar
Valves2
Pump flow7 gpm
26.5 lpm
Tractor hitch
Rear TypeI
Rear lift (at ends)3080 lbs
1397 kg
Power Take-off (PTO)
Rear PTO Type540
Dimensions & Tires
Wheelbase56 inches
142 cm
Weight3223 lbs
1461 kg
Front tire9.5/9x24
Rear tire10.5x20
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
A55 Cultitrac references literature
Cultitrac A20 published in 1972, by Holder
