Tractors > Valtra > T171

Valtra T171

Valtra T171 tractor photo
2007 - 2012   T Series
Row-Crop tractor
Previous model:Valtra T170






Production:

Manufacturer:Valtra


Variants:

T171 Classic:mechanical transmission and hydraulic control
T171 HiTech:electronic transmission, mechanical hydraulics
T171 Advance:eletronic transmission and hydraulic control


Valtra T171 Engine:

   Sisu Diesel 7.4L 6-cyl diesel
full engine details ...


Capacity:

Fuel:43.6 gal [165.0 L] (main)
 44.9 gal [169.9 L] (auxiliary)


3-Point Hitch:

Rear Type:III
Rear lift:16,980 lbs [7702 kg]
 17,860 lbs [8101 kg] (Advance)
Front lift:7,716 lbs [3499 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:ground/540/540E/1000
Front PTO:optional
Front RPM:1000


Dimensions & Tires:

Wheelbase:108.2 inches [274 cm]
Weight:13,120 lbs [5951 kg]
Front tire:460/85R30
Rear tire:20.8R42
full dimensions and tires ...


T171 Serial Numbers:


- Serial numbers unknown -



Valtra T171 Power:

Engine:180 hp [134.2 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:hydraulic disc
Cab:Cab standard with air-conditioning.


Hydraulics:

Pressure:2843 psi [196.0 bar]
 2973 psi [205.0 bar] (Advance)
Pump flow:19.3 gpm [73.1 lpm]
 30.4 gpm [115.1 lpm] (Advance)


Electrical:

Ground:negative
Charging system:alternator


Battery:

Volts:12
Amp-hours:184


Page information:
