Valtra T171


Valtra T171 tractor photo
2007 - 2012
T Series
Row-Crop tractor
T170
Series:T171
Production
Manufacturer:Valtra
Type:Row-Crop tractor
Variants
T171 Classic:mechanical transmission and hydraulic control
T171 HiTech:electronic transmission, mechanical hydraulics
T171 Advance:eletronic transmission and hydraulic control
Valtra T171 Power
Engine:180 hp
134.2 kW
Valtra T171 Engine
Sisu Diesel 7.4L 6-cyl diesel
Fuel tank:43.6 gal
165.0 L (main)
 44.9 gal
169.9 L (auxiliary)
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:hydraulic disc
Cab:Cab standard with air-conditioning.
Transmission:36-speed
Transmission details ...
Photos
No photos of the Valtra T171 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure:2843 psi
196.0 bar
 2973 psi
205.0 bar (Advance)
Pump flow:19.3 gpm
73.1 lpm
 30.4 gpm
115.1 lpm (Advance)
Tractor hitch
Rear Type:III
Rear lift:16,980 lbs
7702 kg
 17,860 lbs
8101 kg (Advance)
Front lift:7,716 lbs
3499 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:ground/540/540E/1000
Front PTO:optional
Front RPM:1000
Dimensions & Tires
Wheelbase:108.2 inches
274 cm
Weight:13,120 lbs
5951 kg
Front tire:460/85R30
Rear tire:20.8R42
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Battery volts:12
Battery AH:184
