CaseIH Maxxum 130

No photo available
2007 - 2014
Model year
Maxxum Series
Row-Crop tractor
Series:Maxxum 125Maxxum 130Maxxum 140
Type:Row-Crop tractor
Factory:Basildon, England
Original price:$94,784 (2011)
CaseIH Maxxum 130 Power
Engine:130 hp
96.9 kW
PTO (claimed):110 hp
82.0 kW
Drawbar (tested):89.2 hp
66.5 kW
PTO (tested):121.4 hp
90.5 kW
power test details ...
CaseIH Maxxum 130 Engine
FPT 4.5L 4-cyl diesel
Fuel tank:46.5 gal
176.0 L
Engine details ...
Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:hydraulic wet disc
Trailer brakes:hydraulic optional
Cab:Cab standard with air-conditioning.
Transmissions:16-speed partial power shift
 17-speed partial power shift
Transmission details ...
No photos of the CaseIH Maxxum 130 are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Type:closed center PFC
Valves:2 to 4
Pump flow:26.5 gpm
100.3 lpm
Total flow:37 gpm
140.0 lpm
Steering flow:10.5 gpm
39.7 lpm
Tractor hitch
Rear Type:2/3N
Control:electronic draft control
Rear lift:9,620 lbs
4363 kg
 12,185 lbs
5527 kg (optional)
Power Take-off (PTO)
Rear PTO:independent
Clutch:electro-hydraulic wet disc
Rear RPM:540/1000
Dimensions & Tires
Wheelbase:94.9 inches
241 cm
Weight:10626 to 12465 pounds
Front tire:14.9R28
Rear tire:18.4R38
Full dimensions and tires ...
Charging system:alternator
Charging amps:120
Battery CCA:960
Battery volts:12
