Tractors > Challenger > MT295B

Challenger MT295B - transmission

Challenger MT295B tractor photo
2005 - 2008   MT200B Series
Compact Utility tractor
Previous model:Challenger MT295
Series next:Challenger MT297B
Series back:Challenger MT285B
more Challenger MT295B specifications...






Transmission:

Transmission:SynchroShuttle
Gears:8 forward and reverse
Clutch:dry
Oil capacity:40.2 qts [38.0 L]
Four non-synchronized gears in two non-synchronized ranges, with synchronized shuttle shift.
Speeds:With 16.9x24 R1 rear tires.
MT295B SynchroShuttle  speeds


Transmission:

Transmission:PowerShuttle
Type:partially synchronized
Gears:12 forward and reverse
Clutch:dry main, wet shuttle
Oil capacity:40.2 qts [38.0 L]
Three ranges with four gears each. Transmission can be shifted from forward to reverse on the go, without the clutch. In-range gear changes can be made on the go with the clutch.
Speeds:With 16.9-24 R1 rear tires.
MT295B PowerShuttle partially synchronized speeds


Transmission:

Transmission:AutoPower IV
Type:partial power shift
Gears:12 forward and reverse
Clutch:mechanical wet disc
Oil capacity:40.2 qts [38.0 L]
Four push-button power shift gears in three non-synchronized ranges. Power shuttle shifting with left-hand console lever. Only available on the MT295B with a cab.
Speeds:With 16.9-24 R1 rear tires.
MT295B AutoPower IV partial power shift speeds
