John Deere 9630T
| | 2007 - 2011 |
| 9030 Series | | Agricultural Crawler tractor |
|
Series map:
9530T
9630T
475.0hp
530.0hp
| Production |
| Manufacturer | John Deere
|
| Agricultural Crawler tractor |
| Built in Waterloo, Iowa, USA |
| John Deere 9630T Power |
| Engine (gross) | 543 hp
404.9 kW
|
| Engine | 530 hp
395.2 kW
|
| PTO (claimed) | 375 hp
279.6 kW
|
| Drawbar (tested) | 401.96 hp
299.7 kW
|
 Performance test details ... |
| Mechanical |
| Drive | crawler
|
| Steering | electro-hydraulic power
|
| Hydraulic wet disc brakes |
| Cab standard with air-conditioning. |
| Capacity |
| Fuel | 330 gal
1249.1 L
|
| Hydraulic system | 27 gal
102.2 L
|
| Hydraulics |
| Type | closed-center pressure flow compensated (PFC)
|
| Capacity | 27 gal
102.2 L
|
| Pressure | 2900 psi
200.0 bar
|
| Pump flow | 48 gpm
181.7 lpm
|
| SCV flow | 30 gpm
113.6 lpm
|
| Tractor hitch |
| Rear Type | 4/4N (optional)
|
| Control | position and draft control
|
| Rear lift | 15,300 lbs
6940 kg
|
| 9630T Serial Number Location |
 |
| Front-right of tractor frame. |
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 200
|
| Batteries | 3
|
| Battery CCA | 925
|
| Battery volts | 12
|
| References |
 |
| New 9030 Series Tractors published in 2007, by John Deere |
