Massey Ferguson 365
|
|
| Production | |
| Manufacturer: | Massey Ferguson |
| Type: | Utility tractor |
| Factory: | Coventry, England |
| Massey Ferguson 365 Power | |
| Engine: | 61 hp 45.5 kW |
| PTO (claimed): | 55 hp 41.0 kW |
| Massey Ferguson 365 Engine | |
| Perkins 3.9L 4-cyl diesel | |
 Engine details ... |
| Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Steering: | power |
| Brakes: | hydraulic wet disc |
| Trailer brakes: | hydraulic*Optional |
| Cab: | Two- or four-post ROPS. Cab available. |
| Transmissions: | 8-speed synchronized |
| 12-speed synchronized | |
| 12-speed two-speed power shift | |
 Transmission details ... | |
| Capacity | |
| Fuel: | 28.5 gal 107.9 L |
| Hydraulic system: | 12.5 gal 47.3 L |
| Hydraulics | |
| Type: | open center |
| Capacity: | 12.5 gal 47.3 L |
| Pressure: | 3000 psi 206.8 bar |
| Pump flow: | 9.5 gpm 36.0 lpm (aux pump) |
| 7.3 gpm 27.6 lpm (hitch pump) | |
| Total flow: | 16.8 gpm 63.6 lpm |
| Tractor hitch | |
| Rear Type: | II/I |
| Control: | position and draft control |
| Rear lift (at ends): | 4729 lbs 2145 kg (II/I interchangeable) *Capacity with links horizontal |
| 5575 lbs 2528 kg (II/I interchangeable with assist ram) *Capacity with links horizontal | |
| 5701 lbs 2585 kg (II fixed) *Capacity with links horizontal | |
| 6744 lbs 3059 kg (II fixed with assist ram) *Capacity with links horizontal | |
| 5410 lbs 2453 kg (II wrist-action) *Capacity with links horizontal | |
| Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540/1000 (1.375) |
| Engine RPM: | 540@1893 1000@1900 |
| Dimensions & Tires | |
| 2WD Wheelbase: | 84.1 inches 213 cm |
| 4WD Wheelbase: | 92.5 inches 234 cm |
| Weight: | 6861 to 7685 pounds |
| Front tire: | 7.50-16 |
| 2WD Rear tire: | 18.4/15-30 |
 Full dimensions and tires ... | |
| 365 Serial Numbers | |
| Location: | Serial number plate on the right side of the tractor, near the brake pedals. |
| Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 45 |
| Battery CCA: | 420 (2x) |
| 540 (1x) | |
| Battery volts: | 12 |
