Farmall B-450


Farmall B-450 tractor photo
1959 - 1970
Row-Crop tractor
Production
Manufacturer:Farmall (a part of International Harvester)
Type:Row-Crop tractor
Factory:Doncaster, England
Total built:11,011
Variants
McCormick B-450:standard
Farmall B-450:row-crop
Farmall B-450 Power
Engine:55 hp
41.0 kW
Farmall B-450 Engine
International Harvester 4.3L 4-cyl diesel
Engine details ...
Mechanical
Chassis:4x2 2WD
Differential lock:mechanical rear
Steering:manual
Cab:Open operator station.
Transmission:5-speed gear
Transmission details ...
Capacity
Fuel:20.9 gal
79.1 L
Hydraulic system:3.6 gal
13.6 L
Hydraulics
Type:open center
Capacity:3.6 gal
13.6 L
Pressure:2000 psi
137.9 bar
Tractor hitch
Rear Type:II
Rear lift:6240 lbs
2830 kg
Power Take-off (PTO)
Rear RPM:540 (1.375)
Engine RPM:555@1500
Dimensions & Tires
Wheelbase:79.5 inches
201 cm
Weight:5930 lbs
2689 kg
Front tire:6.00x16
Rear tire:13.00x30
Full dimensions and tires ...
B-450 Serial Numbers
1959:501
1960:657
1961:1980
1962:3047
1963:5638
1964:6919
1965:8042
1966:9696
1967:10380
1968:10764
1969:11027
1970:11162

how to read serial numbers...

Belt Pulley
Diameter:11 inches
27 cm
RPM:929.6
Speed:2677 ft/min
815.95 meters/min
