Farmall Super AM
|
|
| Production | |
| Manufacturer | Farmall (a part of International Harvester) |
| Row-Crop tractor | |
| Built in Geelong, Australia | |
| Variants | |
| Super AW-6 | kerosense engine, standard front |
| Super AWD-6 | diesel engine, standard front |
| Super AM | kerosene engine, row-crop front |
| Super AMD | diesel engine, row-crop front |
| Farmall Super AM Engine | |
| International Harvester 4.3L 4-cyl kerosene | |
| Fuel tank | 21 gal 79.5 L |
| Aux. fuel | 0.9 gal 3.4 L |
 Engine details ... | |
| Farmall Super AM Transmission | |
| 5-speed unsynchronized gear | |
 Transmission details ... |
| Farmall Super AM Power |
| Mechanical | |
| Two-wheel drive | |
| Differential mechanical drum brakes | |
| Open operator station. |
| Photos | |
| No photos of the Farmall Super AM are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 |
| Engine RPM | 540@1450 |
| Dimensions & Tires | |
| Wheelbase | 88.5 inches 224 cm |
| Weight | 5293 to 6669 pounds |
| Front tire | 6.00x16 |
| Rear tire | 12x38 |
 Full dimensions and tires ... | |
| Super AM Serial Numbers | |
| Location: | Tractor's clutch housing on the right side. |
| Belt Pulley | |
| Diameter | 11 inches 27 cm |
| Width | 7.5 inches 19 cm |
| RPM | 899 |
| Speed | 2588 ft/min 788.82 meters/min |
| Electrical | |
| Charging system | generator |
| References | |
 | |
| International Harvester Australia: Geelong Works by Sarah Tomac* | |
| International Harvester Tractors & Equipment in Australia & New Zealand by Graeme Quick | |
| *Publication contains known errors. |
