Tractors > John Deere > 6610

John Deere 6610



John Deere 6610 tractor photo
1997 - 2001
6000 TEN Series
Row-Crop tractor
Series map:
6510
6610
6810
78.3kw
85.0kw
93.2kw
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Mannheim, Baden-Württemberg, Germany
John Deere 6610 Engine
John Deere 6.8L 6-cyl diesel
Fuel tank54.7 gal
207.0 L
Engine details ...
John Deere 6610 Transmission
24-speed
Transmission details ...
John Deere 6610 Power
Engine114 hp
85.0 kW
PTO (claimed)101 hp
75.3 kW
Mechanical
Four-wheel drive
Power steering
ROPS. Cab optional.
Photos
John Deere 6610
John Deere 6610 photos...
Hydraulics
Typeclosed-center load sensing
Pressure2900 psi
200.0 bar
Pump flow14.3 gpm
54.1 lpm
 15.9 gpmOptOptional
60.2 lpm
 16.6 gpmOptOptional
62.8 lpm
 25.4 gpmOptOptional
96.1 lpm
Tractor hitch
Rear TypeII
Rear Armstelescopic link ends
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
Engine RPM540@2143
 540E@1684
 1000@2208
Front PTOindependent
Front PTO Type1000
Engine RPM1000@2185
Dimensions & Tires
Wheelbase104.3 inches
264 cm
Weight10400 lbs
4717 kg
Front tire16.9R26
Rear tire18.4R38
Full dimensions and tires ...
6610 Serial Numbers
Location:Plate located on right side of main tractor frame.
Electrical
Groundnegative
Charging systemalternator
Charging amps90
 115
Battery volts12
References
6610 references literature
Operator's Manual 6510, 6610, 6810 and 6910 Tractors (OMAL116300) published in 1999
