| | Production: |
| Manufacturer: | Kubota
|
| | Variants: |
| L2600F: | 2WD
|
| L2600DT: | 4WD
|
| | |
| Kubota 1.4L 3-cyl diesel |
| full engine details ... | | | Capacity: |
| Fuel: | 8.2 gal [31.0 L]
|
| | |
| Rear Type: | I
|
| Rear lift (at ends): | 1,985 lbs [900 kg]
|
| | |
| Rear PTO: | live
|
| Rear RPMs: | 540
|
| | |
| Wheelbase: | 61.2 inches [155 cm] (2WD)
|
| | 61.6 inches [156 cm] (4WD)
|
| Weight: | 2116 to 2359 pounds
|
| Front tire: | 5.00-15
|
| Rear tire: | 11.2-24
|
| full dimensions and tires ... | | | |
| front-end loader |
| backhoe |
| all L2600 attachments ... | | | L2600 Serial Numbers: |
- Serial numbers unknown -
|
|
|
|
| | Kubota L2600 Power: |
| Engine (gross): | 27 hp [20.1 kW]
|
| PTO (claimed): | 22.5 hp [16.8 kW]
|
| | Mechanical: |
| Chassis: | 4x2 2WD (L2600F)
|
| | 4x4 MFWD 4WD (L2600DT)
|
| Steering: | manual (2WD)
|
| | power (4WD)
|
| Brakes: | wet disc
|
| Cab: | Two-post ROPS.
|
| | Hydraulics: |
| Type: | open center
|
| Total flow: | 4.6 gpm [17.4 lpm] (2WD)
|
| | 7.2 gpm [27.3 lpm] (4WD)
|
| | Electrical: |
| Ground: | negative
|
| | Battery: |
| Number: | 1
|
| Cold-cranking amps: | 490
|
| Volts: | 12
|
