Renault 145-14 TX
| | 1981 - 1986 |
| TX Series | | Row-Crop tractor |
|
| Production |
| Manufacturer: | Renault
|
| Type: | Row-Crop tractor
|
| Renault 145-14 TX Power |
| Engine: | 132.8 hp
99.0 kW
|
| PTO (claimed): | 127.5 hp
95.1 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | hydraulic dry disc
|
| Cab: | Cab standard with heat.
|
| Transmissions: | 12-speed synchronized
|
| | 16-speed creeper
|
 Transmission details ... |
| Hydraulics |
| Pressure: | 2611 psi
180.0 bar
|
| Total flow: | 11 gpm
41.6 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Control: | position and draft control
|
| Rear lift: | 11668 lbs
5292 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | cerametallic
|
| Rear RPM: | 540/1000 (1.375)
|
| Engine RPM: | 644@2350
1105@2350
|
| Electrical |
| Charging amps: | 70
|
| Batteries: | 2
|
| Battery volts: | 12
|
| Battery AH: | 150
|
| Page information |
| Last update: | January 19, 2022
|
| Copyright: | Copyright 2022 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
©2000-2022 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Renault 145-14 TX photos...
Full dimensions and tires ...
