Tractors > Cub Cadet > 7254

Cub Cadet 7254 - engine

Cub Cadet 7254 tractor photo
2003 - 2003   7000 Series
Compact Utility tractor
Series next:Cub Cadet 7264
Series back:Cub Cadet 7252
more Cub Cadet 7254 specifications...






Engine Detail:

 Kawasaki FD750
 gasoline
 2-cylinder
 liquid-cooled
 45.6 ci [0.7 L]
Bore/Stroke:3.07x3.07 inches [78 x 78 mm]
Power:25 hp [18.6 kW]
Fuel system:dual carburetor
Air cleaner:paper element
Pre-heating:coolant heater (optional)
Rated RPM:3600
Idle RPM:1550-3600
Starter:electric
Starter volts:12
Oil capacity:2.1 qts [2.0 L]
Oil change:100 h
Coolant capacity:3.5 qts [3.3 L]
Coolant change:400 h
Sparkplug gap:0.030 inches [0.762 mm]
Intake valve clearance:0.006 inches [0.152 mm] (cold)
Exhaust valve clearance:0.006 inches [0.152 mm] (cold)
