Massey-Harris 101 Junior



Massey-Harris 101 Junior tractor photo
1939 - 1946
Row-Crop tractor
Series map:
101 Junior
29.2hp*
*Estimated engine power for comparison only.
Production
ManufacturerMassey-Harris
Row-Crop tractor
Built in Racine, Wisconsin, USA
Massey Harris model 101 Junior gasoline tractors that were destined for the export market were marked as a "102G".
Variants
101 Juniorgasoline
102 Juniordistillate
Massey-Harris 101 Junior Engines
Continental 2.0L 4-cyl gasoline
Continental 2.3L 4-cyl gasoline
Continental 2.7L 4-cyl gasoline
Fuel tank10 gal
37.9 L
Engine details ...
Massey-Harris 101 Junior Transmission
4-speed gear
Transmission details ...
Massey-Harris 101 Junior Power
Drawbar (claimed)20.5 hp
15.3 kW
PTO (claimed)26.3 hp
19.6 kW
Plows2
Drawbar (tested)24.65 hp
18.4 kW
Belt (tested)30.56 hp
22.8 kW
Performance test details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
Massey Harris 101 Junior with tricycle front end.
Massey-Harris 101 Junior photos...
Power Take-off (PTO)
Rear PTO Type540 (1.375)
Dimensions & Tires
Wheelbase83.5 inches (row-crop)
212 cm
 78 inches (standard)
198 cm
Weight3400 lbs
1542 kg
Front tire5.00-15
Rear tire10.00-36
Full dimensions and tires ...
101 Junior Serial Numbers
Location:On frame, rear-left side near transmission case
1939375001 (row-crop)
1940376158 (row-crop)
1941395570 (row-crop)
1942397637 (row-crop)
1943398596 (row-crop)
1944500003 (row-crop)
1945502434 (row-crop)
1946503779 (row-crop)
1939377001
1940377928
1941379550
1942379815
1943379855
1944380641
1945382569
1946384298

FAQ: How to read a serial number table.
Belt Pulley
Diameter13 inches
33 cm
Width6 inches
15 cm
RPM837
Speed2958 ft/min
901.60 meters/min
References
101 Junior references literature
101-Jr Tractor published in 1941, by Massey-Harris
