Massey Ferguson 5470


Massey Ferguson 5470 tractor photo
2005 - 2013
Model year
5400 Series
Utility tractor
Series map:
5465
5470
109.0hp
125.0hp
Production
ManufacturerMassey Ferguson
Utility tractor
Built in Beauvais, France
Variants
5470SAlow-profile and narrow, special applications
Massey Ferguson 5470 Engine
Sisu 4.4L 4-cyl diesel
Fuel tank38 gal
143.8 L
 55 gal (with optional tank)
208.2 L
Engine details ...
Massey Ferguson 5470 Power
Engine125 hp
93.2 kW
Drawbar (claimed)89 hp
66.4 kW
PTO (claimed)105 hp
78.3 kW
Drawbar (tested)88.5 hp
66.0 kW
PTO (tested)110.6 hp
82.5 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Power steering
Independent hydraulic wet disc brakes
cab standard
Hydraulics
Typeopen center
 closed OptOptional
Pressure2900 psi
200.0 bar
Valves2 to 5
Total flow15 gpm (open)
56.8 lpm
 34.8 gpm (combined flow)
131.7 lpm
 29 gpm (closed)
109.8 lpm
Tractor hitch
Rear TypeII
Rear lift (at 24"/610mm)7000 lbs
3175 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
 540E/1000 OptOptional
Dimensions & Tires
Wheelbase105.1 inches
266 cm
Weight9545 to 10385 pounds
Front tire10.00-16
Rear tire18.4R38
Full dimensions and tires ...
Electrical
Groundnegative
Charging amps80
 120 OptOptional
Battery CCA505
Battery volts12
References
5470 references literature
5400 Series published in 2006, by Massey Ferguson
