Massey Ferguson 5470 Tests

Massey Ferguson 5470 tractor photo
2005 - 2013
Model year
5400 Series
Utility tractor
Series map:
OCED Tractor Test 2359
5470 fuel use from test 559
OCED Tractor Test 2359
Diesel 16-speed 4WD
May 2006 - 2006,
Link: OCED Tractor Test 2359 file
PTO performance
Max power110.6 hp
82.5 kW
Fuel use6.0 gal/hour
22.7 l/hour
Power at rated engine speed108.0 hp
80.5 kW
Fuel use6.3 gal/hour
23.8 l/hour
Power at rated PTO speed110.5 hp
82.4 kW
Fuel use6.0 gal/hour
22.7 l/hour
Drawbar performance
Max power88.5 hp
66.0 kW
Fuel use6.4 gal/hour
24.2 l/hour
Gear 9 used for power test.
Max pull9510 lbs
4313 kg
Gear 1D used for pull test.
