Tractors > Massey Ferguson > 5455

Massey Ferguson 5455

Massey Ferguson 5455 tractor photo
2005 - 2013   5400 Series
Model years
Utility tractor
Series next:Massey Ferguson 5460
Series back:Massey Ferguson 5445






Production:

Manufacturer:Massey Ferguson
Factory:Beauvais, France


Massey Ferguson 5455 Engine:

   Perkins 4.4L 4-cyl diesel
full engine details ...


Capacity:

Fuel:40 gal [151.4 L]
 53.2 gal [201.4 L] (with optional tank)


3-Point Hitch:

Rear Type:II
Rear lift (at 24"/610mm):7,000 lbs [3175 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540/1000
 540E/1000 (optional)


Dimensions & Tires:

Wheelbase:97 inches [246 cm]
Weight:8675 to 9305 pounds
Front tire:10.00-16
Rear tire:18.4R38
full dimensions and tires ...


5455 Serial Numbers:


- Serial numbers unknown -



Massey Ferguson 5455 Power:

Engine:95 hp [70.8 kW]
Drawbar (claimed):67 hp [50.0 kW]
PTO (claimed):80 hp [59.7 kW]
Drawbar (tested):66.8 hp [49.8 kW]
PTO (tested):82.6 hp [61.6 kW]
power test details ...


Mechanical:

Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:hydrostaic power
Brakes:independent hydraulic wet disc
Cab:ROPS, cab optional


Hydraulics:

Type:open center
 closed optional
Pressure:2900 psi [200.0 bar]
Valves:2 to 4
Total flow:15 gpm [56.8 lpm] (open)
 34.8 gpm [131.7 lpm] (combined flow)
 29 gpm [109.8 lpm] (closed)


Electrical:

Ground:negative
Charging amps:80


Battery:

Cold-cranking amps:505
Volts:12
