McCormick Intl MTX125
|
|
| Production | |
| Manufacturer | McCormick Intl (a part of Argo) |
| Row-Crop tractor | |
| Built in Doncaster, England | |
| McCormick Intl MTX125 Engine | |
| Perkins 6.0L 6-cyl diesel | |
| Fuel tank | 70 gal 264.9 L |
 Engine details ... | |
| McCormick Intl MTX125 Transmissions | |
| 16-speed four-speed power shift | |
| 32-speed creeper | |
 Transmission details ... |
| McCormick Intl MTX125 Power | |
| Engine | 130 hp 96.9 kW |
| Drawbar (claimed) | 99 hp 73.8 kW |
| PTO (claimed) | 112 hp 83.5 kW |
| Drawbar (tested) | 99.1 hp 73.9 kW |
| PTO (tested) | 114.1 hp 85.1 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | electro-hydraulic rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Cab standard with air-conditioning. | |
| Hydraulics | |
| Type | pressure flow compensating |
| Pump flow | 28.8 gpm 109.0 lpm |
| SCV flow | 25.1 gpm 95.0 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | electronic lower link draft sensing |
| Rear lift (at 24"/610mm) | 8201 lbs 3719 kg |
| 10180 lbs (optional) 4617 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@1877 |
| 1000@2200 | |
| Dimensions & Tires | |
| Wheelbase | 106.3 inches 270 cm |
| Weight | 12020 to 13620 pounds |
| Front tire | 14.9R28 |
| Rear tire | 18.4R38 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 95 |
| Battery volts | 12 |
| References | |
 | |
| MTX Series published in 2000, by McCormick |
