Tractors > Buhler Versatile > 2210

Buhler Versatile 2210

Buhler Versatile 2210 tractor photo
2000 - 2008   Genesis Series
Row-Crop tractor
Next model:Versatile 280
Series back:Buhler Versatile 2180





This is the same tractor as the New Holland 8970


Production:

Manufacturer:Buhler Versatile
Factory:Winnipeg, Manitoba, Canada
Original price (USD)
   $117,000 (2008 )


Buhler Versatile 2210 Engine:

   New Holland 7.5L 6-cyl diesel
full engine details ...


Capacity:

Fuel:110 gal [416.4 L]
Hydraulic system:37 gal [140.0 L]


3-Point Hitch:

Rear Type:3
Control:electronic draft sensing
Rear lift:15000 lbs [6804 kg]


Power Take-off (PTO):

Rear PTO:independent
Clutch:wet disc
Rear RPM:1000 (1.75)
 1000 (1.375)*Optional
Engine RPM:1000@1903


Dimensions & Tires:

Standard Steer Wheelbase:118.3 inches [300 cm]
Ultra Steer Wheelbase:122.6 inches [311 cm]
Weight:19,625 lbs [8901 kg]
Front tire:16.9R30
Rear tire:20.8R42
full dimensions and tires ...


2210 Serial Numbers:


- Serial numbers unknown -



Buhler Versatile 2210 Power:

Engine:275 hp [205.1 kW]
PTO (claimed):210 hp [156.6 kW]
Drawbar (tested):189.5 hp [141.3 kW]
PTO (tested):224.6 hp [167.5 kW]
power test details ...


Mechanical:

Chassis:4x4 MFWD 4WD
Steering:power
Brakes:wet disc
Cab:Cab standard with air-conditioning.


Hydraulics:

Type:closed center load-sensing
Capacity:37 gal [140.0 L]
Pressure:2900 psi [200.0 bar]
Valves:3 or 4
Total flow:30 gpm [113.6 lpm]
 55 gpm [208.2 lpm] *Optional HydraFlow.


Electrical:

Ground:negative
Charging system:alternator
Charging amps:130


Battery:

Number:2
Cold-cranking amps:950
Volts:12
