Tractors > McCormick-Deering > TA-40

McCormick-Deering TA-40

McCormick-Deering TA-40 tractor photo
1932 - 1936
Agricultural Crawler tractor
Next model:McCormick-Deering T-40






Production:

Manufacturer:McCormick-Deering (a part of International Harvester)
Factory:Chicago, Illinois, USA
Total built:1,313


McCormick-Deering TA-40 Engine:

   International Harvester 4.6L 6-cyl gasoline
full engine details ...


Capacity:

Fuel:42 gal [159.0 L]


Dimensions & Tires:

Weight:10790 lbs [4894 kg]
Front tire:tracks
Rear tire:tracks
full dimensions and tires ...


TA-40 Serial Numbers:

Location:Seat, right side
1932: 501
1933: 834
1934: 1471
1935: 3086
1936: 4649
Final: 6624

how to read serial numbers...



McCormick-Deering TA-40 Power:

Drawbar (claimed):35 hp [26.1 kW]
Belt (claimed):45 hp [33.6 kW]
Drawbar (tested):42.72 hp [31.9 kW]
Belt (tested):46.48 hp [34.7 kW]
power test details ...


Mechanical:

Chassis:crawler
Cab:Open operator station.


Belt Pulley:

Diameter:16.75 inches [42 cm]
Width:9 inches [22 cm]
RPM:603.8
