AGCO ST52A


No photo available
2005 - 2008
ST-A Series
Compact Utility tractor
Iseki built
Series map:
ST47A
ST52A
ST60A
47.5hp
52.1hp
46.4hp
Production
DistributorAGCO
ManufacturerIseki
Compact Utility tractor
Built in Matsuyama, Japan
AGCO ST52A Engine
Iseki 3.0L 4-cyl diesel
Engine details ...
AGCO ST52A Transmissions
8-speed synchro shuttle
12-speed power shuttle
12-speed four-speed power shift
Transmission details ...
AGCO ST52A Power
Engine (gross)52.1 hp
38.9 kW
PTO (claimed)41 hp
30.6 kW
Mechanical
Four-wheel drive
Final drivesspur gear
Differential lockmechanical rear
Power steering
Wet disc brakes
ROPS. Cab optional with air-conditioning.
Photos
No photos of the AGCO ST52A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pump flow12.5 gpm
47.3 lpm
Tractor hitch
Rear TypeI
Controlposition control with optional draft control
Rear lift (at ends)3483 lbs
1579 kg
Rear lift (at 24"/610mm)3086 lbs
1399 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Dimensions & Tires
Wheelbase75 inches
190 cm
Weight3582 lbs
1624 kg
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
ST52A references literature
ST Series published in 2004, by AGCO
ST Series published in 2004, by AGCO*
*Publication contains known errors.
