AGCO ST41A


AGCO ST41A tractor photo
2005 - 2008
ST-A Series
Compact Utility tractor
Iseki built
Series map:
ST34A
ST41A
ST47A
33.0hp
40.1hp
47.5hp
Production
DistributorAGCO
ManufacturerIseki
Compact Utility tractor
Built in Matsuyama, Japan
AGCO ST41A Engine
Iseki 1.5L 3-cyl diesel
Engine details ...
AGCO ST41A Transmissions
8-speed synchro shuttle
12-speed power shuttle
hydrostatic
Transmission details ...
AGCO ST41A Power
Engine (gross)40.1 hp
29.9 kW
Hydro PTO (claimed)29.5 hp
22.0 kW
Gear PTO (claimed)31 hp
23.1 kW
Mechanical
Four-wheel drive
Final drivesspur gear
Differential lockmechanical rear
Power steering
Wet disc brakes
Two-post folding ROPS.
Photos
No photos of the AGCO ST41A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pump flow9.1 gpm
34.4 lpm
Tractor hitch
Rear TypeI
Controlposition control with optional draft control
Rear lift (at ends)2800 lbs
1270 kg
Rear lift (at 24"/610mm)2535 lbs
1149 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Mid PTOindependent OptOptional
Mid PTO Type2000
Dimensions & Tires
Wheelbase70 inches
177 cm
Weight2888 lbs
1309 kg
Full dimensions and tires ...
AGCO ST41A attachments
60" mid-mount mower deck
72" mid-mount mower deck
front-end loader
backhoe
Attachment details ...
Electrical
Groundnegative
Battery volts12
References
ST41A references literature
ST Series published in 2004, by AGCO
ST Series published in 2004, by AGCO*
*Publication contains known errors.
