McCormick Intl XTX200


McCormick Intl XTX200 tractor photo
2005 - 2007
XTX Series
Row-Crop tractor
MTX185
Series:XTX185XTX200XTX215
TTX210
Production
Manufacturer:McCormick Intl (a part of Argo)
Type:Row-Crop tractor
Factory:Doncaster, England
The McCormick XTX200 is similar to the McCormick MTX185.
McCormick Intl XTX200 Power
Engine:195.8 hp
146.0 kW
Drawbar (tested):140.38 hp
104.7 kW
PTO (tested):192.3 hp
143.4 kW
power test details ...
McCormick Intl XTX200 Engine
Iveco 6.7L 6-cyl diesel
Fuel tank:91.7 gal
347.1 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:wet disc
Transmissions:32-speed
 48-speed
Transmission details ...
Photos
No photos of the McCormick Intl XTX200 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:PFC
Total flow:34.1 gpm
129.1 lpm
 43.1 gpm
163.1 lpm (optional)
Tractor hitch
Rear Type:III
Rear lift:24,144 lbs
10951 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000
 540E/1000 (optional)
Dimensions & Tires
Wheelbase:113.1 inches
287 cm
Weight:15880 to 16010 pounds
Front tire:540/65R30
Rear tire:650/65R42
Full dimensions and tires ...
Electrical
Charging amps:120
