Tractors > New Holland > Boomer TZ24DA

New Holland Boomer TZ24DA

New Holland Boomer TZ24DA tractor photo
2003 - 2004   Boomer TZ Series
Sub-Compact Utility tractor
Next model:New Holland TZ25DA
Series next:New Holland TZ25DA
Series back:New Holland TZ22DA





The New Holland TZ24DA is similar to the Shibaura SX24.


Production:

Manufacturer:New Holland


New Holland TZ24DA Engine:

   Shibaura 1.0L 3-cyl diesel
full engine details ...


Capacity:

Fuel:7.9 gal [29.9 L]


3-Point Hitch:

Rear Type:I
Rear lift (at 24"/610mm):700 lbs [317 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540 (1.375)
Mid PTO:standard
Mid RPM:2200


Dimensions & Tires:

Weight:1456 lbs [660 kg]
full dimensions and tires ...


New Holland TZ24DA attachments:

 mowing deck
 front-end loader
all TZ24DA attachments ...


TZ24DA Serial Numbers:


- Serial numbers unknown -



New Holland TZ24DA Power:

Engine (gross):24 hp [17.9 kW]
PTO (claimed):18 hp [13.4 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:wet disc
Cab:Two-post ROPS.


Hydraulics:

Type:open center
Pump flow:3.75 gpm [14.2 lpm]
Total flow:5.6 gpm [21.2 lpm]
Steering flow:1.85 gpm [7.0 lpm]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:36


Battery:

Number:1
Cold-cranking amps:325
Volts:12
