    Allis Chalmers M

    Allis Chalmers M tractor photo
    1932 - 1942
    Agricultural Crawler tractor






    Production:

    Manufacturer:Allis Chalmers
    Factory:Springfield, Illinois, USA
    Total built:14,524


    Variants:

    M:standard width
    WM:wide


    Allis Chalmers M Engines:

       Allis Chalmers 4.9L 4-cyl gasoline
       Allis Chalmers 5.2L 4-cyl gasoline
    full engine details ...


    Capacity:

    Fuel:24 gal [90.8 L]


    Dimensions & Tires:

    Weight:6,200 lbs [2812 kg]
    Front tire:tracks
    Rear tire:tracks
    full dimensions and tires ...


    M Serial Numbers:

    Location:Right side of transmission case
    1933: 1
    1934: 402
    1935: 842
    1936: 1942
    1937: 3842
    1938: 7067
    1939: 8127
    1940: 9540
    1941: 11380
    1942: 12947

    how to read serial numbers...



    Allis Chalmers M Power:

    Drawbar (claimed):22 hp [16.4 kW]
    Belt (claimed):32 hp [23.9 kW]
    Drawbar (tested):29.65 hp [22.1 kW]
    Belt (tested):35.43 hp [26.4 kW]
    power test details ...


    Mechanical:

    Chassis:crawler
    Cab:Open operator station.


    Battery:

    Volts:6
