Tractors > Allis Chalmers > 25-40 E

Allis Chalmers 25-40 E

Allis Chalmers 25-40 E tractor photo
1930 - 1936
Standard-tread tractor
Previous model:Allis Chalmers 20-35
Next model:Allis Chalmers A






Production:

Manufacturer:Allis Chalmers
Factory:West Allis, Wisconsin, USA
Total built:2,426


Allis Chalmers 25-40 Engines:

   Allis Chalmers 8.4L 4-cyl gasoline
   Allis Chalmers 9.2L 4-cyl
full engine details ...


Capacity:

Fuel:30 gal [113.6 L]
Aux. fuel:1 gal [3.8 L]


Dimensions & Tires:

Weight:7,000 lbs [3175 kg]
Front tire:36x6
Rear tire:50x12
full dimensions and tires ...


25-40 Serial Numbers:

Location:front of shifter on transmission case
1930: 24186
1931: 24843
1932: 24972
1933: 25024
1934: 25062
1935: 25309
1936: 25582
Final: 25611

how to read serial numbers...



Allis Chalmers 25-40 Power:

Drawbar (claimed):27 hp [20.1 kW]
Belt (claimed):42.6 hp [31.8 kW]
Drawbar (tested):33.82 hp [25.2 kW]
Belt (tested):47.00 hp [35.0 kW]
power test details ...


Mechanical:

Chassis:4x2 2WD
Steering:manual
Cab:Open operator station.
