Century C35


No photo available
2005 - 2006
Compact Utility tractor
Kukje built
Series:C29C35C38
Production
Distributor:Century
Manufacturer:Kukje
Type:Compact Utility tractor
Factory:Yangsu-ri, South Korea
Century C35 Power
Engine:35 hp
26.1 kW
PTO (claimed):30 hp
22.4 kW
Century C35 Engine
Kukje 1.7L 3-cyl diesel
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Differential lock:foot pedal
Steering:hydrostatic power
Brakes:differential wet disc
Cab:ROPS.
Transmission:12-speed partially synchronized
Transmission details ...
Photos
No photos of the Century C35 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:10.6 gal
40.1 L
Hydraulic system:9.25 gal
35.0 L
Front axle:7.4 qts
7.0 L
Hydraulics
Type:open center
Capacity:9.25 gal
35.0 L
Valves:1 to 3
Pump flow:8.9 gpm
33.7 lpm
Total flow:13.2 gpm
50.0 lpm
Tractor hitch
Rear Type:I
Rear lift (at ends):2,580 lbs
1170 kg
Power Take-off (PTO)
Rear PTO:live (2-stage clutch)
Rear RPM:540/1000
Dimensions & Tires
Wheelbase:65 inches
165 cm
Weight:3,640 lbs
1651 kg
Front tire:7-16
Rear tire:12.4-24
Full dimensions and tires ...
C35 Serial Numbers
Location:Rear of tractor below PTO.
Electrical
Ground:negative
Charging amps:45
Battery volts:12
