Lamborghini Champion 120

Lamborghini Champion 120 tractor photo
1998 - 2004   Champion Series
Row-Crop tractor






Production:

Manufacturer:Lamborghini


Lamborghini Champion 120 Engine:

   SDF 6.0L 6-cyl diesel
full engine details ...


Capacity:

Fuel:60.8 gal [230.1 L]
 100.4 gal [380.0 L] *Optional


3-Point Hitch:

Rear lift:15432 lbs [6999 kg]
 18960 lbs [8600 kg] *With optional lift cylinders.
Front lift:8818 lbs [3999 kg] *Optional


Power Take-off (PTO):

Rear PTO:independent
Clutch:electro-hydraulic wet disc
Rear RPM:540/1000
 540E/1000
Front PTO:independent*Optional
Clutch:electro-hydraulic
Front RPM:1000


Dimensions & Tires:

Wheelbase:108.3 inches [275 cm]
Weight:13448 lbs [6100 kg]
Front tire:420/70R28
Rear tire:520/70R34
full dimensions and tires ...


Champion 120 Serial Numbers:


how to read serial numbers...



Lamborghini Champion 120 Power:

Engine:120 hp [89.5 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Differential lock:electro-hydraulic front and rear
Steering:power
Brakes:hydraulic wet disc
Trailer brakes:hydraulic*Optional
Cab:Cab standard with air-conditioning.


Hydraulics:

Type:open center
 load-sensing*Optional
Valves:8*Optional
Pump flow:19.3 gpm [73.1 lpm] (open)
 27.2 gpm [103.0 lpm] (load-sensing)


Electrical:

Charging system:alternator
