Volvo T36


Volvo T36 tractor photo
1953 - 1959
T30 Series
Row-Crop tractor
Production
Manufacturer:Volvo
Type:Row-Crop tractor
Total built:1632
The Volvo T36 was the same as the Bolinder Munktell BM36.
Variants
T35:standard
T36:row-crop
Volvo T36 Power
Engine:41.9 hp
31.2 kW
PTO (claimed):37.5 hp
28.0 kW
Volvo T36 Engine
Bolinder 3.4L 3-cyl diesel
Fuel tank:17.2 gal
65.1 L
Engine details ...
Mechanical
Chassis:4x2 2WD
Steering:manual
Cab:Open operator station.
Transmission:5-speed gear
Transmission details ...
Photos
No photos of the Volvo T36 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Rear RPM:540 (1.375)
Engine RPM:540@1500
Dimensions & Tires
Wheelbase:79.1 inches
200 cm
Weight:5424 lbs
2460 kg
Front tire:6.00x19
Rear tire:11x38
Full dimensions and tires ...
Electrical
Charging system:generator
Battery volts:12
