Tractors > McCormick Intl > CX95

McCormick Intl CX95

No photo available
2003 - 2007   CX Series
Utility tractor
Series next:McCormick Intl CX105
Series back:McCormick Intl CX85






Production:

Manufacturer:McCormick Intl
Factory:Doncaster, England


McCormick Intl CX95 Engines:

   Perkins 4.0L 4-cyl diesel
   Perkins 4.4L 4-cyl diesel
full engine details ...


Capacity:

Fuel:41 gal [155.2 L]
Hydraulic system:9.1 gal [34.4 L] (2WD)
 9.7 gal [36.7 L] (4WD)


3-Point Hitch:

Rear lift:8,543 lbs [3875 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540/1000
Engine RPM:540@2000
1000@2000


Dimensions & Tires:

Wheelbase:92.91 inches [235 cm]
Weight:8312 to 8467 pounds
Front tire:10.00-16
Rear tire:16.9R34
full dimensions and tires ...


CX95 Serial Numbers:


- Serial numbers unknown -



McCormick Intl CX95 Power:

Engine (net):90 hp [67.1 kW]
Engine:90 hp [67.1 kW]
PTO (claimed):74 hp [55.2 kW]


Mechanical:

Chassis:4x2 2WD
 4x4 MFWD 4WD (optional)
Steering:hydrostatic power
Cab:ROPS. Cab optional.


Hydraulics:

Type:open center
Capacity:9.1 gal [34.4 L] (2WD)
 9.7 gal [36.7 L] (4WD)
Pump flow:15.85 gpm [60.0 lpm]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:65


Battery:

Volts:12


Page information:
