    McCormick Intl CX75

    McCormick Intl CX75 tractor photo
    2003 -
    Larger:McCormick Intl CX85






    Production:

    Manufacturer:McCormick Intl
    Factory:Doncaster, England


    McCormick Intl CX75 Engines:

       Perkins 4.2L 4-cyl diesel
       Perkins 4.4L 4-cyl diesel
    full engine details ...


    Capacity:

    Fuel:41 gal [155.2 L]
    Hydraulic system:9.1 gal [34.4 L] (2WD)
     9.7 gal [36.7 L] (4WD)


    3-Point Hitch:

    Rear lift:4,498 lbs [2040 kg]


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPMs:540/1000
    Engine RPMs:540@2000
    1000@2000


    Dimensions & Tires:

    Wheelbase:92.91 inches [235 cm]
    Weight:8312 lbs [3770 kg]
    Front tire:7.50-16
    Rear tire:16.9R34
    full dimensions and tires ...


    CX75 Serial Numbers:


    - Serial numbers unknown -



    McCormick Intl CX75 Power:

    Engine (net):73 hp [54.4 kW]
    Engine:73 hp [54.4 kW]
    PTO (claimed):60 hp [44.7 kW]
    Drawbar (tested):50.2 hp [37.4 kW]
    PTO (tested):59.7 hp [44.5 kW]
    power test details ...


    Mechanical:

    Chassis:4x2 2WD
     4x4 MFWD 4WD (optional)
    Steering:hydrostatic power
    Brakes:hydraulic wet disc
    Cab:ROPS. Cab optional.


    Hydraulics:

    Type:open center
    Capacity:9.1 gal [34.4 L] (2WD)
     9.7 gal [36.7 L] (4WD)
    Pump flow:15.85 gpm [60.0 lpm]


    Electrical:

    Ground:negative
    Charging system:alternator
    Charging amps:65


    Battery:

    Volts:12
