    John Deere 8530

    John Deere 8530 tractor photo
    2006 - 2009   8030 Series
    Row-Crop tractor
    Previous model:John Deere 8520
    Next model:John Deere 8345R
    Smaller:John Deere 8430






    Production:

    Manufacturer:John Deere
    Factory:Waterloo, Iowa, USA


    John Deere 8530 Engine:

       John Deere 9.0L 6-cyl diesel
    full engine details ...


    Capacity:

    Fuel:180 gal [681.3 L]
    Hydraulic system:9.5 gal [36.0 L]
     14.5 gal [54.9 L] (with aux reservoir)


    3-Point Hitch:

    Rear Type:IVN/III
    Rear lift (at 24"/610mm):18,326 lbs [8312 kg]


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPM:1000
     540/1000 (optional)
    Engine RPM:540@1817
    1000@2000


    Dimensions & Tires:

    Wheelbase:118.9 inches [302 cm]
    Weight:26,800 lbs [12156 kg]
    full dimensions and tires ...


    8530 Serial Numbers:

    Location:Rear of tractor
    photo of 8530 serial number

    2006: 1001
    2007: 10005
    2008: 20007
    2009: 40000

    how to read serial numbers...



    John Deere 8530 Power:

    Engine (gross):330 hp [246.1 kW]
    Engine (max):360 hp [268.5 kW]
    PTO (claimed):275 hp [205.1 kW]
    Drawbar (tested):240.35 hp [179.2 kW]
    PTO (tested):312.73 hp [233.2 kW]
    power test details ...


    Mechanical:

    Chassis:4x4 Independent Link Suspension (ILS) MFWD 4WD
    Steering:hydrostatic power
    Brakes:hydraulic wet disc
    Cab:CommandView cab standard.


    Hydraulics:

    Type:closed center pressure-flow compensating PFC
    Capacity:9.5 gal [36.0 L]
     14.5 gal [54.9 L] (with aux reservoir)
    Pressure:2990 psi [206.2 bar]
    Valves:3 to 5
    Pump flow:31.7 gpm [120.0 lpm]
    Total flow:60 gpm [227.1 lpm]


    Electrical:

    Ground:negative
    Charging system:alternator
    Charging amps:200


    Battery:

    Number:2
    Cold-cranking amps:925
    Volts:12
