Fendt Farmer 104S
|
|
| Production | |
| Manufacturer | Fendt |
| Row-Crop tractor | |
| Fendt Farmer 104S Engine | |
| MWM 3.1L 3-cyl diesel | |
| Fuel tank | 17.2 gal 65.1 L |
 Engine details ... | |
| Fendt Farmer 104S Transmissions | |
| 13-speed synchronized | |
| 16-speed creeper | |
 Transmission details ... |
| Fendt Farmer 104S Power | |
| Engine | 54 hp 40.3 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Steering | manual |
| Steering | power OptOptional |
| Mechanical drum brakes | |
| Four-post ROPS. | |
| Photos | |
| No photos of the Fendt Farmer 104S are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | II/I |
| Rear lift | 4410 lbs 2000 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@2164 |
| 1000@2251 | |
| Dimensions & Tires | |
| 2WD Wheelbase | 83.5 inches 212 cm |
| 4WD Wheelbase | 81.1 inches 205 cm |
| Weight | 5467 to 6129 pounds |
| Front tire | 6.50-20 |
| 2WD Rear tire | 12.4/11-38 |
 Full dimensions and tires ... | |
| References | |
 | |
| Farmer 104S published in 1972, by Fendt |
