AGCO Allis 9650
| | 1994 - 1995 |
| 9600 Series | | Row-Crop tractor |
|
Series map:
9630
9650
9670
150.0hp*
172.2hp*
194.4hp*
*Estimated engine power for comparison only.
| Production |
| Manufacturer | AGCO Allis (a part of AGCO)
|
| Row-Crop tractor |
| Original price was $77,000 in 1995 |
| AGCO Allis 9650 Power |
| PTO (claimed) | 155 hp
115.6 kW
|
| Drawbar (tested) | 138.03 hp
102.9 kW
|
| PTO (tested) | 159.30 hp
118.8 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Final drives | inboard planetary
|
| Differential lock | electro-hydraulic rear
|
| Power steering |
| Hydraulic wet disc brakes |
| Cab standard with air-conditioning. |
| Photos |
| No photos of the AGCO Allis 9650 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | closed center pressure-compensating
|
| Pressure | 2250 psi
155.1 bar
|
| Rear valves | 3 or 4
|
| Pump flow | 24 gpm*Claimed. During testing, actual flow was 22.5 GPM.
90.8 lpm
|
| Tractor hitch |
| Rear Type | III/II
|
| Control | lower-link draft sensing
|
| Rear lift (at 24"/610mm) | 7212 lbs*During testing, actual lift was 5913 pounds.
3271 kg
|
| | 8544 lbs*Claimed lift with optional assist cylinder. During testing, actual lift was 6962 pounds.
3875 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | hydraulic wet disc
|
| Rear RPM | 540/1000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 105
|
| Batteries | 2
|
| Battery CCA | 580
|
| Battery volts | 12
|
| References |
 |
| 9600/9800 Series Tractors published by AGCO |
| 9600 Series published in 1991, by AGCO |
