AGCO Allis 9435

AGCO Allis 9435 tractor photo
1994 - 1997   9400 Series
Row-Crop tractor
Series next:AGCO Allis 9455






Production:

Manufacturer:AGCO
Original price (USD)
   $70,000 (1997 )


Variants:

9435:32-speed semi-powershift
9635:18-speed full powershift


AGCO Allis 9435 Engine:

   Detroit Diesel 7.6L 6-cyl diesel
full engine details ...


Capacity:

Fuel:76 gal [287.7 L]


3-Point Hitch:

Rear Type:III/II
Control:electronic lower-link draft sensing
Rear lift (at 24"/610mm):10400 lbs [4717 kg]
Rear Arms:extendible lower links


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540/1000


Dimensions & Tires:

2WD Wheelbase:123.2 inches [312 cm]
4WD Wheelbase:116.5 inches [295 cm]
Weight:13800 to 15432 pounds
Front tire:11.00-16
2WD Rear tire:18.4R38
full dimensions and tires ...


9435 Serial Numbers:

Location:Console, right side
1994: 935001
1995: 935501
1996: 936301
1997: 936369

how to read serial numbers...



AGCO Allis 9435 Power:

PTO (claimed):135 hp [100.7 kW]
Drawbar (tested):120.26 hp [89.7 kW]
PTO (tested):143.78 hp [107.2 kW]
power test details ...


Mechanical:

Chassis:4x2 2WD
 4x4 MFWD 4WD
Final drives:inboard planetary
Differential lock:electro-hydraulic
Steering:power
Brakes:hydraulic wet disc
Cab:Cab standard with air-conditioning.


Hydraulics:

Type:closed center
Pressure:2900 psi [200.0 bar]
Valves:3 or 4
Pump flow:27 gpm [102.2 lpm]


Electrical:

Ground:negative
Charging system:alternator


Battery:

Volts:12
