John Deere 5410


John Deere 5410 tractor photo
1998 - 2001
5000 Ten Series
Utility tractor
Series map:
5310
5410
5510
64.0hp
81.0hp
89.0hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Augusta, Georgia, USA
Original price was $27,532 in 2001
John Deere 5410 Engine
John Deere 4.5L 4-cyl diesel
ROPS Fuel tank18 gal
68.1 L
Cab Fuel tank23 gal
87.1 L
Engine details ...
John Deere 5410 Transmissions
9-speed unsynchronized gear
9-speed partially synchronized
12-speed power shuttle
Transmission details ...
John Deere 5410 Power
Engine81 hp
60.4 kW
PTO (claimed)65 hp
48.5 kW
PTO (tested)66.49 hp
49.6 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Power steering
Hydraulic wet disc brakes
Two-post ROPS. Cab optional.
Hydraulics
Typeopen center
Pressure2855 psi
196.9 bar
Valves5
Pump flow16.4 gpm
62.1 lpm
Total flow23 gpm
87.1 lpm
Steering flow6.6 gpm
25.0 lpm
Steering press.1955 psi
134.8 bar
Tractor hitch
Rear TypeI/II
Rear lift (at 24"/610mm)3,374 lbs
1530 kg
Power Take-off (PTO)
Rear PTOindependent
Rear RPM540
 540/540E *540E PTO with SyncShuttle transmission.
Dimensions & Tires
Wheelbase85.7 inches*The Deere operator's manual incorrectly states 80.7 inches.
217 cm
Weight5000 to 6500 pounds
Front tire7.50-16
2WD Rear tire16.9-30
Full dimensions and tires ...
5410 Serial Numbers
1998140000
1999240001
2000340000
2001440000

FAQ: How to read a serial number table.
5410 Serial Location
John Deere 5410 serial number location
The serial number plate is on the right side of the John Deere 5410 tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemalternator
ROPS Charging amps40
Cab Charging amps60
Battery CCA700
Battery volts12
ROPS Battery Group28H
Cab Battery Group31
References
5410 references literature
Golf and Turf Equipment Purchasing Guide published in 1998, by John Deere
Grounds Care Equipment Purchasing Guide published in 1999, by John Deere
Grounds Care Equipment Purchasing Guide published in 2000, by John Deere
Operator's Manual 5210, 5310, 5410 and 5510 Tractors (OMRE71736) published in 1996
New 5000 Ten Series published in 1998, by John Deere
