Kubota L4630


Kubota L4630 tractor photo
2003 - 2007
L30 Series
Compact Utility tractor
Series map:
L4330
L4630
L5030
43.2hp
47.2hp
52.2hp
Production
ManufacturerKubota
Compact Utility tractor
Variants
L4630DT4WD 8 speed
L4630GST4WD 12 speed
L4630HSThydro
L4630GSTCcab
Kubota L4630 Engine
Kubota 2.2L 4-cyl diesel
Fuel tank10.6 gal
40.1 L
Engine details ...
Kubota L4630 Transmissions
hydrostatic
8-speed fully synchronized
12-speed power shift
24-speed
Transmission details ...
Kubota L4630 Power
Engine (gross)47.2 hp
35.2 kW
Engine (net)44.7 hp
33.3 kW
Gear PTO (claimed)39.5 hp
29.5 kW
Hydro PTO (claimed)38 hp
28.3 kW
Mechanical
Four-wheel drive
Power steering
Wet disc brakes
Two-post folding ROPs. Grand Cab optional.
Photos
No photos of the Kubota L4630 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Valves3 OptOptional
Pump flow9.8 gpm
37.1 lpm
Total flow14.7 gpm
55.6 lpm
Steering flow4.9 gpm
18.5 lpm
Tractor hitch
Rear TypeI
Controlposition control with optional draft control
Rear lift (at 24"/610mm)2760 lbs
1251 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Mid PTOindependent OptOptional
Mid PTO Type2000
Dimensions & Tires
Wheelbase74.6 inches
189 cm
Weight3440 to 3815 pounds
Front tire8.3-16
Rear tire14.9-24
Full dimensions and tires ...
Kubota L4630 attachments
snowblower
blade
front-end loader
backhoe
Attachment details ...
L4630 Serial Numbers
Location:Serial number decal on the left side of the tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemalternator
ROPS Charging amps40
Cab Charging amps60
Battery volts12
References
L4630 references literature
Grand L 30 Series published in 2004, by Kubota*
*Publication contains known errors.
