    Kubota L5040

    Kubota L5040 tractor photo
    2007 -    L40 Series
    Larger:Kubota L5240
    Smaller:Kubota L4740





    The "semi-independent" mid PTO is linked with the rear PTO. Whenever the mid PTO is engaged, the rear PTO will also be engaged. The rear PTO can be run without the mid PTO.


    Production:

    Manufacturer:Kubota
    Original price (USD):$28,871 (2011)


    Kubota L5040 Engine:

       Kubota 2.4L 4-cyl diesel
    full engine details ...


    Capacity:

    Fuel:14.3 gal [54.1 L]
    Hydraulic system:11.9 gal [45.0 L]
    Front axle:9.5 qts [9.0 L]


    3-Point Hitch:

    Rear Type:I
    Rear lift (at ends):3,680 lbs [1669 kg]
    Rear lift (at 24"/610mm):2,760 lbs [1251 kg]


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPMs:540
    Engine RPMs:540@2550
    Mid PTO:semi-independent (optional)
    Mid RPMs:2000


    Dimensions & Tires:

    Wheelbase:75.4 inches [191 cm]
    Weight:3,803 lbs [1725 kg]
    Front tire:9.5-16
    Rear tire:14.9-26
    full dimensions and tires ...


    Kubota L5040 attachments:

     snowblower
     blade
     front-end loader
     backhoe
    all L5040 attachments ...


    L5040 Serial Numbers:


    - Serial numbers unknown -



    Kubota L5040 Power:

    Engine (gross):52 hp [38.8 kW]
    Engine (net):50 hp [37.3 kW]
    PTO (claimed):44 hp [32.8 kW]


    Mechanical:

    Chassis:4x4 MFWD 4WD
    Differential lock:standard
    Steering:hydrostatic power steering
    Brakes:mechanical wet disc
    Cab:Two-post foldable ROPS.


    Hydraulics:

    Type:open center
    Capacity:11.9 gal [45.0 L]
    Valves:2 to 3
    Pump flow:9.4 gpm [35.6 lpm]
    Total flow:14.1 gpm [53.4 lpm]
    Steering flow:4.7 gpm [17.8 lpm]


    Electrical:

    Ground:negative
    Charging amps:45


    Battery:

    Number:1
    Cold-cranking amps:582
    Volts:12
