    Ford 950

    Ford 950 tractor photo  FO-20 I&T Manual: Ford 501, 600, 601, 700, 701, 800, 801, 900, 901, 1801, 2000, 4000
    I&T Shop Manual
    1954 - 1957   900 Series
    Row-Crop tractor
    Next model:Ford 951






    Production:

    Manufacturer:Ford
    Factory:Highland Park, Michigan, USA


    Variants:

    850:utility chassis
    960:live PTO


    Ford 950 Engines:

       Ford 2.8L 4-cyl gasoline
       Ford 2.8L 4-cyl LP gas
    full engine details ...


    Capacity:

    Hydraulic system:2 gal [7.6 L]


    3-Point Hitch:

    Rear Type:I
    Rear lift:1,250 lbs [567 kg]


    Power Take-off (PTO):

    Rear PTO:transmission
    Rear RPMs:540


    Dimensions & Tires:

    Wheelbase:85.3 inches [216 cm]
    Weight:3280 to 6475 pounds
    Front tire:6x16
    Rear tire:12x28
    full dimensions and tires ...


    950 Serial Numbers:


    - Serial numbers unknown -



    Ford 950 Power:

    Belt (claimed):40 hp [29.8 kW]
    Plows:3 (14-inch)


    Mechanical:

    Chassis:4x2 2WD
    Steering:manual
     power assist optional
    Brakes:differential mechanical expanding shoe
    Cab:Open operator station.


    Hydraulics:

    Type:open
    Capacity:2 gal [7.6 L]


    Electrical:

    Ground:positive
    Charging system:generator
    Charging amps:20


    Battery:

    Number:1
    Volts:6
