    CaseIH MXM155 Maxxum

    CaseIH MXM155 Maxxum tractor photo
    2002 - 2007   Maxxum Series
    Row-Crop tractor
    Previous model:CaseIH MX150
    Larger:CaseIH MXM175
    Smaller:CaseIH MXM140






    Production:

    Manufacturer:CaseIH
    Factory:Basildon, England


    CaseIH MXM155 Engine:

       CNH 7.5L 6-cyl diesel
    full engine details ...


    Capacity:

    Fuel:75 gal [283.9 L]
    Hydraulic system:23.75 gal [89.9 L]


    3-Point Hitch:

    Rear Type:III/II
    Control:electronic lower-link sensing
    Rear lift (at 24"/610mm):11,690 lbs [5302 kg]


    Power Take-off (PTO):

    Rear PTO:independent
    Clutch:electro-hydraulic
    Rear RPMs:540/1000 (1.375)


    Dimensions & Tires:

    Wheelbase:108.1 inches [274 cm] (2WD)
     107.2 inches [272 cm] (4WD)
    Weight:12,920 lbs [5860 kg]
    full dimensions and tires ...


    MXM155 Serial Numbers:


    - Serial numbers unknown -



    CaseIH MXM155 Power:

    PTO (claimed):125 hp [93.2 kW]
    Drawbar (tested):108.5 hp [80.9 kW]
    PTO (tested):133.8 hp [99.8 kW]
    power test details ...


    Mechanical:

    Chassis:4x2 2WD
     4x4 MFWD 4WD optional
    Steering:hydrostatic pwoer
    Brakes:differential hydraulic wet disc


    Hydraulics:

    Type:closed-center load sensing
    Capacity:23.75 gal [89.9 L]
    Pressure:2750 psi [189.6 bar]
    Valves:2 to 5
    Pump flow:25 gpm [94.6 lpm]
    Total flow:28 gpm [106.0 lpm] (implement pump)
     44 gpm [166.5 lpm] (total)


    Electrical:

    Ground:negative
    Charging system:alternator
    Charging amps:120


    Battery:

    Number:1
    Cold-cranking amps:1300
    Volts:12
    Amp-hours:176
