Tractors > CaseIH > Farmall DX18E

CaseIH Farmall DX18E

CaseIH Farmall DX18E tractor photo
2004 - 2008   DXE Series
Sub-Compact Utility tractor






Production:

Manufacturer:CaseIH


CaseIH Farmall DX18E Engine:

   Shibaura 1.0L 3-cyl diesel
full engine details ...


Capacity:

Fuel:7.9 gal [29.9 L]


3-Point Hitch:

Rear Type:I
Rear lift (at 24"/610mm):700 lbs [317 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540
Mid PTO:standard
Mid RPM:2200


Dimensions & Tires:

Wheelbase:55 inches [139 cm]
Weight:1,314 lbs [596 kg]
full dimensions and tires ...


CaseIH Farmall DX18E attachments:

 mowing deck
 snowblower
 blade
 front-end loader
all Farmall DX18E attachments ...


Farmall DX18E Serial Numbers:


- Serial numbers unknown -



CaseIH Farmall DX18E Power:

Engine:18 hp [13.4 kW]
PTO (claimed):13.7 hp [10.2 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Cab:Two-post ROPS. Canopy and soft cab optional.


Hydraulics:

Type:open center
Total flow:5.5 gpm [20.8 lpm]


Electrical:

Ground:negative


Battery:

Number:1
Volts:12
