John Deere 5225
|
|
| Production | |
| Manufacturer: | John Deere |
| Type: | Utility tractor |
| Factory: | Augusta, Georgia, USA |
| John Deere 5225 Power | |
| Engine (gross): | 56 hp 41.8 kW |
| PTO (claimed): | 45 hp 33.6 kW |
| PTO (tested): | 47.59 hp 35.5 kW |
| John Deere 5225 Engine | |
| John Deere 3.1L 5-cyl diesel | |
 Engine details ... |
| Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Final drives: | inboard planetary |
| Differential lock: | mechanical rear |
| Steering: | power |
| Brakes: | differential hydraulic wet disc |
| Cab: | Open operator station with two-post folding ROPS. Optional isolated flat-platform (IOOS). Cab available with air-conditioning. |
| Transmissions: | 9-speed partially synchronized |
| 12-speed power shuttle | |
| 24-speed two-speed power shift | |
 Transmission details ... | |
| Photos | |
 | |
 John Deere 5225 photos... | |
| Capacity | |
| Fuel: | 25 gal 94.6 L (straddle) |
| 33.5 gal 126.8 L (IOOS/cab) | |
| Hydraulic system: | 10.3 gal 39.0 L (9-speed) |
| 11.5 gal 43.5 L (12-speed) | |
| Front hubs: | 0.74 qts 0.7 L *Each |
| Front diff.: | 4.8 qts 4.5 L |
| Hydraulics | |
| Type: | open center |
| Capacity: | 10.3 gal 39.0 L (9-speed) |
| 11.5 gal 43.5 L (12-speed) | |
| Pressure: | 2828 psi 195.0 bar |
| Rear valves: | 1 to 3 |
| Mid valves: | 0, 2 or 3 |
| Pump flow: | 13.5 gpm 51.1 lpm |
| Total flow: | 19.4 gpm 73.4 lpm |
| Steering flow: | 5.9 gpm 22.3 lpm |
| Steering press.: | 1957 psi 134.9 bar |
| Tractor hitch | |
| Rear Type: | II/I |
| Control: | top-link draft sensing |
| Rear lift (at 24"/610mm): | 3374 lbs 1530 kg |
| Power Take-off (PTO) | |
| Rear PTO: | independent |
| Clutch: | dry disc |
| electro-hydraulic wet disc (24-speed) | |
| Rear RPM: | 540 |
| 540/540E*Optional | |
| 540/1000*Optional field conversion kit. | |
| Engine RPM: | 540@2400 540E@1700 |
| Dimensions & Tires | |
| Wheelbase: | 85.7 inches 217 cm |
| Weight: | 5350 to 6580 pounds |
| Front tire: | 6.50-16 |
| 2WD Rear tire: | 13.6-28 |
 Full dimensions and tires ... | |
| John Deere 5225 attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| 5225 Serial Numbers | |
| Location: | Left side of tractor frame above the front axle. |
| 2005: | 120001 |
| 2006: | 220001 |
| 2007: | 320001 |
| 2008: | 420001 |
| Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| ROPS Charging amps: | 70 |
| Cab Charging amps: | 90 |
| Battery CCA: | 950 |
| Battery volts: | 12 |
| Battery Group: | BCI 31 |
