John Deere 9420T Transmission


John Deere 9420T tractor photo
2002 - 2007
9020 Series
Agricultural Crawler tractor
9400T
Series:9320T9420T9520T
9430T
Transmissions overview
18-speed full power shift
24-speed partial power shift
Transmission
Transmission:John Deere PowerShift
Type:full power shift
Gears:18 forward and 6 reverse
Oil capacity:240 qts
227.1 L
 244 qts
230.9 L (with PTO)
Speeds
9420T PowerShift full power shift speeds
Transmission
Transmission:John Deere PowrSync
Type:partial power shift
Gears:24 forward and 6 reverse
Oil capacity:256 qts
242.3 L
 260 qts
246.1 L (with PTO)
Four synchronized ranges (A-D) with three synchronized gears (1-3) and a high-low power shift.
Speeds
9420T PowrSync partial power shift speeds
