Kubota L3300


Kubota L3300 tractor photo
1994 - 1999
Grand L Series
Compact Utility tractor
Series map:
L2900
L3300
L3600
32.1hp
35.1hp
38.5hp
Production
ManufacturerKubota
Compact Utility tractor
Kubota L3300 Engine
Kubota 1.6L 3-cyl diesel
Fuel tank9.2 gal
34.8 L
Engine details ...
Kubota L3300 Transmissions
8-speed synchronized shuttle
8-speed power shuttle
Transmission details ...
Kubota L3300 Power
Engine (gross)35.1 hp
26.2 kW
Engine (net)32.5 hp
24.2 kW
PTO (claimed)28 hp
20.9 kW
Plows2 (12-inch)
 1 (16-inch)
Mechanical
Two- or four-wheel drive
Power steering
Wet disc brakes
Two-post ROPS.
Hydraulics
Typeopen center
Pressure2490 psi
171.7 bar
Total flow7.0 gpm
26.5 lpm
Tractor hitch
Rear TypeI
Controlposition control
Rear lift (at ends)2,870 lbs
1301 kg
Rear lift (at 24"/610mm)2,200 lbs
997 kg
Power Take-off (PTO)
Rear PTOindependent
Rear RPM540 (1.375)
Engine RPM540@2670
Mid PTOindependent
Mid RPM2000
Engine RPM2000@2623
Dimensions & Tires
2WD Wheelbase65.9 inches
167 cm
4WD Wheelbase67.5 inches
171 cm
Weight2610 to 2765 pounds
Front tire5.00-15
Rear tire12.4-24 (2WD)
Full dimensions and tires ...
Kubota L3300 attachments
72" mid-mount mower deck
snowblower
blade
front-end loader
backhoe
Attachment details ...
Electrical
Groundnegative
Battery CCA490
Battery volts12
References
L3300 references literature
Backhoes published in 1994, by Kubota
Mid-Mount Mowers B/L Series published in 1994, by Kubota
Front Loaders B, L and M-Series published in 1994, by Kubota
L2900/L3300/L3600/L4200 published in 1996, by Kubota
