Kubota L285


Kubota L285 tractor photo
1975 - 1981
Compact Utility tractor
Production
ManufacturerKubota
Compact Utility tractor
Kubota L285 Engine
Kubota 1.5L 4-cyl diesel
Fuel tank9.2 gal
34.8 L
Engine details ...
Kubota L285 Power
Engine30 hp
22.4 kW
PTO (claimed)26.5 hp
19.8 kW
Mechanical
Two-wheel drive
Differential lockmechanical rear
Open operator station.
Hydraulics
Typeopen center
Pump flow4.7 gpm
17.8 lpm
Tractor hitch
Rear TypeI
Rear lift2535 lbs
1149 kg
Power Take-off (PTO)
Rear RPM540 (1.375)
Engine RPM540@2070
1000@2105
Front PTOindependent
Clutchelecro-magnetic
Dimensions & Tires
Wheelbase67 inches
170 cm
Weight2230 lbs
1011 kg
Front tire5.00-15
Rear tire12.4-24
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
L285 references literature
New Model L285 published in 1975, by Kubota
Diesel L285 Tractor published in 1978, by Kubota
