    Kubota B5200

    Kubota B5200 tractor photo
    1983 - 1996
    Previous model:Kubota B5100
    Larger:Kubota B6200HST
    Smaller:Kubota B4200






    Production:

    Manufacturer:Kubota
    Factory:Japan
    Original price (USD):$8,250 (1990 4WD)


    Variants:

    B5200E:2WD
    B5200D:4WD


    Kubota B5200 Engine:

       Kubota 0.8L 3-cyl diesel
    full engine details ...


    Capacity:

    Fuel:3.8 gal [14.4 L]
    Hydraulic system:3.2 gal [12.1 L]


    3-Point Hitch:

    Rear Type:I
    Rear lift:1,036 lbs [469 kg]


    Power Take-off (PTO):

    Rear PTO:transmission
    Rear RPMs:540/825
    Front PTO:optional
    Front RPMs:2500


    Dimensions & Tires:

    Wheelbase:55.1 inches [139 cm]
    Weight:1058 to 1180 pounds
    Front tire:4.5-10
    Rear tire:7-16
    full dimensions and tires ...


    Kubota B5200 attachments:

     snowblower
     front-end loader
    all B5200 attachments ...


    B5200 Serial Numbers:

    1983: 10003
    1984: 11800
    1985: 30003
    1986: 48216
    1987: 66409
    1988: 74602
    1989: 82795
    1990: 90488
    1991: 97681
    1992: 104372

    how to read serial numbers...



    Kubota B5200 Power:

    Engine (gross):13 hp [9.7 kW]
    PTO (claimed):11.5 hp [8.6 kW]
    Plows:1 (12-inch)


    Mechanical:

    Chassis:4x2 2WD
     4x4 MFWD 4WD (B5200D)
    Steering:manual
    Brakes:dry internal expanding
    Cab:Two-post ROPS.


    Hydraulics:

    Type:open center
    Capacity:3.2 gal [12.1 L]
    Pressure:1630 psi [112.4 bar]
    Total flow:4 gpm [15.1 lpm]


    Electrical:

    Charging system:alternator
    Charging amps:35 (optional)
