Tractors > CaseIH > 4694

CaseIH 4694 - transmission

CaseIH 4694 tractor photo
1984 - 1987   4WD 94 Series
Four-wheel Drive (4WD) tractor
Previous model:J.I. Case 4694
Series next:CaseIH 4894
Series back:CaseIH 4494
more CaseIH 4694 specifications...



Transmission:partial power shift
Gears:12 forward and 4 reverse
Clutch:hydraulic wet disc
Four ranges (1-4) with three power shift gears (1-3) plus reverse in each range. Both shift levers mounted on the dashboard. Range shift lever is to the left in a H-pattern. Gear shift is an inline pattern on the right.
Speeds:With 23.1x30 tires.
4694 partial power shift  speeds
CaseIH 4694 partial power shift transmission photo
